Beskrivelse
GPU Engine Specs
CUDA Cores : 10752
Boost Clock (MHz) : 2617MHz
Base Clock (MHz) : 2295MHz
Thermal and Power Spec
Minimum System Power Requirement (W) : 850W
Supplementary Power Connectors : 3x PCIe 8-pin cables (adapter in box) OR 1x 450 W or greater PCIe Gen 5 cable
Memory Specs
Memory Clock : 30Gbps
Standard Memory Config : 16GB
Memory Interface : GDDR7
Memory Interface Width : 256-bit
Memory Bandwidth (GB/sec) : 960 GB/sec
Feature Support
Real-Time Ray Tracing : Yes
Ray Tracing Cores : 4th Generation, 171 TFLOPS
Tensor Cores : 5th Generation, 1801 AI TOPS
NVIDIA Architecture : Blackwell
Microsoft DirectX : 12 Ultimate
NVIDIA DLSS : 4
NVIDIA Ansel : Yes
NVIDIA FreeStyle : Yes
Bus Support : PCI Express Gen 5
NVIDIA ShadowPlay : Yes
OS Certification : Windows 11 / 10, Linux, FreeBSDx86
NVIDIA Highlights : Yes
NVIDIA G-SYNC™-Ready : Yes
Game Ready Drivers : Yes
NVIDIA Studio Drivers : Yes
NVIDIA GPU Boost™ : Yes
Vulkan API : 1.4
OpenGL : 4.6
NVIDIA Encoder : 2x Ninth Generation
NVIDIA Decoder : 2x Sixth Generation
Grafikkortets dimensioner:
Længde: 300 mm
Højde: 116 mm
Bredde: 41 mm
Længde: 300 mm
Højde: 116 mm
Bredde: 41 mm
Skærm / monitor Support
Multi Monitor : up to 4
Maxmium Digital Resolution : 4K at 480Hz or 8K at 165Hz with DSC
HDCP : 2.3
Standard Display Connectors : 3x DisplayPort 2.1b, 1x HDMI 2.1b
